SCOM ULTRA Carbon Spoke Wheelset

The ultimate racer’s edge.

A stiff, aerodynamic wheelset built to do one thing: win races. A choice of rim depths for every parcours, but all laced to fast-rolling hubs with carbon spokes.

  • From 1280g
  • Carbon Spokes
  • ENDURO bearings
  • Five-Year Warranty
  • 21mm Internal Rim Width
  • Tubeless Ready
  • Zero-coating rim finish
  • Rim depth range from 45 to 67mm.

Born to Race

We made full use of our motorsports expertise and resources to develop the SCOM ULTRA wheelset. We had one goal: build a wheelset to win races. Every aspect of the wheel is designed to give top athletes the very best in performance.

Features

Fast, Strong Hubs



The heart of any strong wheelset is a strong hub. Our hubs are precision machined from the strongest alloys with oversized bearings, axles and flanges - all with the goal of increasing stiffness. Any flex at the hub will be amplified by the time it reaches the rim, therefore a stiff, solid hub is paramount.

Lightweight



Although in comparison to the system weight of the rider + bicycle the wheelset wieght is a small percentage it nevertheless cannot be overlooked. Thanks to using only premium materials, the resulting weight of a wheelset is as little as 1,280g.

Durability by Design



The old adage says "to finish first, you must first finish." For this reason we designed a wheelset that had durability as a core principle. Durable steel Enduro bearings are just a part of that philosophy. Or wheels are designed to handle the forces of top-level racing, and we have a five year warranty to stand behind them.

Carbon Spokes



We've been using carbon spokes on our race car wheels for years, so when it came to choosing a material for our bike wheel spokes, carbon was the obvious choice. Lighter and stiffer than the best steel spokes, carbon spokes provide snappy acceleration and high lateral stiffness for fast cornering.

Specific Models

SCOM Ultra 45/45 Disc Brake

  • 1350g (±3%)
  • 45mm/45mm Rim Depth
  • 19mm Internal / 26mm External rim width

SCOM Ultra 49/67 Disc Brake

  • 1510g (±3%)
  • 49mm/67mm Rim Depth
  • 21mm Internal / 28mm External rim width

SCOM Ultra 67/67 Disc Brake

  • 1540g (±3%)
  • 67mm/67mm Rim Depth
  • 21mm Internal / 28mm External rim width

SCOM Ultra 45/45 Rim Brake

  • 1280g (±3%)
  • 45mm/45mm Rim Depth
  • 19mm Internal / 26mm External rim width

SCOM Ultra 49/67 Rim Brake

  • 1440g (±3%)
  • 49mm/67mm Rim Depth
  • 21mm Internal / 28mm External rim width

SCOM Ultra 67/67 Rim Brake

  • 1480g (±3%)
  • 67mm/67mm Rim Depth
  • 21mm Internal / 28mm External rim width

Disc Brake Specifications

  • Rim: SCOM Zero-Coating Rim
  • Hub: SCOM Disc Brake Hubs
  • Bearings: Enduro
  • Freehub Body Options: Shimano Compatible, SRAM XDR Compatible, Campagnolo Compatible
  • Freehub Body Engagement Angle: 6 Degrees
  • Axle Type: Front 100x12mm, Rear 142x12mm Thru Axles
  • ETRTO: 21-622
  • Rim Width: As above
  • Rim Depth: As above
  • Tire Compatibility: Clincher, Tubeless
  • Colour Options: Black, Gold, Silver (Subject to availability.)
  • Spoke Count: Front 21, Rear 24

Rim Brake Specifications

  • Rim: SCOM Zero-Coating Rim
  • Hub: SCOM Rim Brake Hubs
  • Bearings: Enduro
  • Freehub Body Options: Shimano Compatible, SRAM XDR Compatible, Campagnolo Compatible
  • Freehub Body Engagement Angle: 6 Degrees
  • Axle Type: 9mm Quick Release Skewers
  • ETRTO: 21-622
  • Rim Width: As above
  • Rim Depth: As above
  • Tire Compatibility: Clincher, Tubeless
  • Colour Options: Black, Gold, Silver (Subject to availability.)
  • Spoke Count: Front 16, Rear 21
